Main User Interface
· From OFF: Quick Click = ON, Press & Hold = Low or first mode in sequence
· From ON: Quick Click = OFF, Press & Hold = Cycle sequence such as Low-Medium-High
Hidden Features (From ON or OFF) 2x Rapid Clicks = 100% Turbo
· 3x Rapid Clicks = Strobe
· 4x Rapid Clicks = Voltage
o Voltage Blinks
§ 5 blinks > 90%
§ 4 blinks > 70%
§ 3 blinks > 50%
§ 2 blinks > 30%
§ 1 blink < 30%
· 5x Rapid Clicks = Bike Strobe
· 6x Rapid Clicks = 1 Hz Blink
· 7x Rapid Clicks = 2 Hz Blink
· 8x Rapid Clicks = Random Hz Techno Strobe
Note: Hidden Features can be activated from ON or OFF.
Note: While in Hidden Features, Quick Click revert back to last mode used.
Note: Hidden Features are disabled when Config. Lock is enabled.
Config Mode
· 10 Quick Clicks from ON or OFF enters Config Mode. Light will blink 5 times if activated or blinks 15 times if Config Mode is locked out.
· Each setting has 3 groups of Clicks.
· Example: 10-1-12 = 10 Clicks, then 1 Click, then 12 Clicks (Blinking confirmation between each set of Clicks.)
* = Default Setting
Mode Group Selection
· The light will turn on in a low level while you are making your selection.
· After selecting the mode group, the light will blink 2 times to confirm the selection.
10-1-1 = 100%
10-1-2 = 70%
10-1-3 = 50%
10-1-4 = 30%
10-1-5 = 15%
10-1-6 = 5%
10-1-7 = FF – 50%
10-1-8 = 5% – 50%
10-1-9 = 20% – 50%
10-1-10 = FF – 20% – 50%
10-1-11= FF – 5% – 15% – 40% – 70%*
10-1-12 = 100%-70%-40%-15%-5%-FF
10-1-13 = FF – 20% – 50%. Lender’s Group with Hidden Features Deactivated.
10-1-14 = Bike 20%, Bike 40%, Bike 70%, 100% Constant ON
FireFly Level Config
10-2-1 = Dim FireFly
10-2-2 = Low FireFly
10-2-3 = Medium FireFly
10-2-4 = High FireFly
10-2-5 = Bright FireFly
Turbo Level Config
10-3-1 = 100%*
10-3-2 = 90%
10-3-3 = 85%
10-3-4 = 80%
10-3-5 = 75%
Turbo Timer Config (Constant Turbo Mode Only)
· Once turbo time is reached, the light begins a slow linear ramp down to 50% that takes ~1 min. to complete.
10-4-1 = TT OFF
10-4-2 = 15s
10-4-3 = 30s *
10-4-4 = 45s
10-4-5 = 1min
10-4-6 = 1.5min
10-4-7 = 2min
10-4-8 = 2.5min
10-4-9 = 3min
10-4-10 = 5min
10-4-11= 7min
10-4-12 = 10min
Temperature Sensor Config
10-5-1
· The light activates at 15% power.
· A click in the first 5 seconds turn the temperature sensor OFF.
· After 5 seconds, the light will turn on at “Turbo” power.
o Click once again once the desired peak temperature is reached.
Battery Insert LED Start-UP
10-6-1 = OFF *
10-6-2 = ON 100%
10-6-3 = ON 50%
10-6-4 = ON 5%
Low Voltage Protection Toggle (Begins at 2.8V/cell under load; shutdown at 2.5V/cell under load).
10-7-1 = LVP Disabled
10-7-2 = LVP Enabled *
10-7-3 = LVP Enabled (Lower Threshold --- For Super High Power Lights)
Light Lock Out Toggle | Done from OFF state. Resets with power reset.
10 Click with 10th Click & Hold
· 1 Blink = Unlocked*
· 2 Blinks = Locked
Turbo Mode Toggle | Done from OFF state. Persists with power reset.
13 Click with 13th Click & Hold
· Constant Turbo = Turbo at 100% until Temp Sensor or Turbo Timer intervene.
· Adaptive Vision Turbo = Turbo / Power Level over 30% for 15s, then a constant ramp down until 30% over a ~10min duration.
o Saves battery, lowers heat, protects circuitry, and allows eyes to adapt.
· 1 Blink = Constant Turbo*
· 2 Blinks = Adaptive Turbo
Config Lock Toggle | Done from OFF state. Persists with power reset.
15 Clicks with 15th Click & Hold
· 1 Blink = Unlocked*
· 2 Blinks = Locked
